Shaft frame lifter SRH03
Art. No.: HTD-35000
Hand-operated hydraulic manhole frame lifter for manhole covers with an outer diameter of 560-625 mm and an inner diameter of up to 800 mm
Further properties
The HT-SHR03 is used for regulation work and renovation of sagging or protruding manhole frames.
The hand-hydraulic 3-arm lifter makes it easy to handle and features individual
detailed solutions. The advantage of the central hydraulic unit is the separately lockable lifting cylinders.
They enable energy-saving and precise execution of the adjustment work.
Made in Germany guarantees robust and reliable operation. A good supply of spare parts ensures a long service life.
- Lifting height: 300 mm (special design: lowering depth can be extended by 100 mm)
- Dimensions: L/W/H 1000/1200/1340 mm
- Inner diameter: 800 mm
- Weight: approx. 200 kg
- Made in Germany = robust and reliable function guaranteed
- Extensive range of accessories available for shaft frame adjustment
- Effortless working = no extensive chiseling work necessary
- Easy handling
Special features
- Hand-operated hydraulic 3-arm lifter is easy to handle
- Separately lockable lifting cylinder = effort-saving and precise execution of adjustment work
- Lifting capacity: 3 x 12 t (total: 36 t)
Application
- Regulation work and renovation of sagging or protruding shaft frames
- For regular work on a small to medium scale
- Suitable for easy lifting of the manhole frame to street level or for complete lifting out
